How to Install Erpnext on Ubuntu 22.04
ERPNext is a free and open-source integrated Enterprise Resource Planning software developed by an Indian software company Frappe Technologies Pvt. Ltd. and is built on MariaDB database system using Frappe, a Python based server-side framework.
Prerequisites
- Ubuntu 22.04 VPS with at least 4GB of RAM and 40GB Disk
- root access or a user with sudo privileges
- A qualified domain or subdomain name
Update the System
Before starting update all Ubuntu 22.04 packages installed on the server are up to date using below command,
apt update -y
apt upgrade -y Create New User
Create a new Frappe Bench User for our ERPNext installation,
sudo adduser (New-Frappe-User)
usermod -aG sudo (New-Frappe-User)
su (New-Frappe-User)
cd /home/(New-Frappe-User)Replace (New-Frappe-User) with the actual username
Install Dependencies
Install required packages using below command,
Install GIT,
sudo apt-get install gitInstall Python3.10, as ERPNext version 14 requires Python 3.10+ version,
sudo apt-get install python3-dev python3.10-dev python3-setuptools python3-pip python3-distutilsInstall virtual environment to manage software at one place,
sudo apt-get install python3.10-venvInstall Software Properties Common,
sudo apt-get install software-properties-commonInstall MariaDB,
sudo apt install mariadb-server mariadb-clientInstall Redis Server,
sudo apt-get install redis-serverOpen redis.conf file and change the redis port to 11000,
nano /etc/redis/redis.conf
port 11000Save the configuration file and restart the redis server using below command,
systemctl restart redisInstall Other Required Packages using below command,
sudo apt-get install xvfb libfontconfig wkhtmltopdf
sudo apt-get install libmysqlclient-dev Configure MYSQL Server
sudo mysql_secure_installationOutput:
Enter current password for root (enter for none): Press your [Enter] key, there is no password set by default
Switch to unix_socket authentication N
Set root password? [Y/n] Y
New password: Enter_Your_Password
Re-enter new password: Enter_Your_Password
Remove anonymous users? [Y/n] Y
Disallow root login remotely? [Y/n] Y
Remove test database and access to it? [Y/n] Y
Reload privilege tables now? [Y/n] YEdit MYSQL default config file,
sudo nano /etc/mysql/my.cnfAdd the following to the file,
[mysqld]
character-set-client-handshake = FALSE
character-set-server = utf8mb4
collation-server = utf8mb4_unicode_ci
[mysql]
default-character-set = utf8mb4Restart the MYSQL Server using below command,
sudo service mysql restart Install CURL, Node, NPM and Yarn
Install CURL,
sudo apt install curlInstall Node 16.15.0,
curl https://raw.githubusercontent.com/creationix/nvm/master/install.sh | bash
source ~/.profile
nvm install 16.15.0Output:
erpnext@vps:~$ nvm install 16.15.0
Downloading and installing node v16.15.0...
Downloading https://nodejs.org/dist/v16.15.0/node-v16.15.0-linux-x64.tar.xz...
################################################################################################################################# 100.0%
Computing checksum with sha256sum
Checksums matched!
Now using node v16.15.0 (npm v8.5.5)
Creating default alias: default -> 16.15.0 (-> v16.15.0)Install NPM,
sudo apt-get install npmInstall Yarn,
sudo npm install -g yarnInstall Frappe Bench,
sudo pip3 install frappe-benchInitialize Frappe Bench,
bench init --frappe-branch version-14 frappe-benchOutput:
erpnext@vps:~$ bench init --frappe-branch version-14 frappe-bench
Setting Up Environment
$ python3 -m venv env
$ /home/erpnext/frappe-bench/env/bin/python -m pip install --quiet --upgrade pip
$ /home/erpnext/frappe-bench/env/bin/python -m pip install --quiet wheel
Getting frappe
$ git clone https://github.com/frappe/frappe.git --branch version-14 --depth 1 --origin upstream
Cloning into 'frappe'...
remote: Enumerating objects: 3210, done.
remote: Counting objects: 100% (3210/3210), done.
remote: Compressing objects: 100% (2893/2893), done.
remote: Total 3210 (delta 425), reused 1758 (delta 216), pack-reused 0
Receiving objects: 100% (3210/3210), 16.96 MiB | 14.92 MiB/s, done.
Resolving deltas: 100% (425/425), done.
Installing frappe
$ /home/erpnext/frappe-bench/env/bin/python -m pip install --quiet --upgrade -e /home/erpnext/frappe-bench/apps/frappe
$ yarn install
yarn install v1.22.19
[1/5] Validating package.json...
[2/5] Resolving packages...
[3/5] Fetching packages...
[############################################################################-------------------------------------------------] 324/530^[4/5] Linking dependencies...
warning " > @frappe/esbuild-plugin-postcss2@0.1.3" has unmet peer dependency "less@^4.x".
warning " > @frappe/esbuild-plugin-postcss2@0.1.3" has unmet peer dependency "stylus@^0.x".
[5/5] Building fresh packages...
$ npm run snyk-protect
> snyk-protect
> snyk-protect
Applied Snyk patches.
npm notice
npm notice New major version of npm available! 8.5.5 -> 9.6.7
npm notice Changelog: https://github.com/npm/cli/releases/tag/v9.6.7
npm notice Run npm install -g npm@9.6.7 to update!
npm notice
Done in 53.22s.
Found existing apps updating states...
WARN: restart failed: Couldn't find supervisorctl in PATH
$ bench build
Assets for Release v14.37.0 don't exist
✔ Application Assets Linked
yarn run v1.22.19
$ node esbuild --production --run-build-command
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
Browserslist: caniuse-lite is outdated. Please run:
npx browserslist@latest --update-db
Why you should do it regularly: https://github.com/browserslist/browserslist#browsers-data-updating
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
clean: postcss.plugin was deprecated. Migration guide:
https://evilmartians.com/chronicles/postcss-8-plugin-migration
File Size
frappe/dist/js/
├─ bootstrap-4-web.bundle.22U72DEL.js 1.73 Kb
├─ controls.bundle.DFF2HAYM.js 1228.77 Kb
├─ data_import_tools.bundle.ZHGGYJ52.js 106.10 Kb
├─ desk.bundle.F6VOTWOZ.js 1422.47 Kb
├─ dialog.bundle.YMH3F5JU.js 54.14 Kb
├─ form.bundle.BQYTYJFC.js 154.02 Kb
├─ frappe-web.bundle.OFX5DKXL.js 952.95 Kb
├─ libs.bundle.YZMCKPNH.js 574.13 Kb
├─ list.bundle.OHONPWA4.js 189.47 Kb
├─ logtypes.bundle.7STJ7YLS.js 0.73 Kb
├─ onboarding_tours.bundle.DSTT3JYE.js 7.38 Kb
├─ recorder.bundle.5AOEUOFD.js 179.54 Kb
├─ report.bundle.IKFONGWA.js 171.58 Kb
├─ telemetry.bundle.PM4NETTP.js 2.12 Kb
├─ user_profile_controller.bundle.YR6XHZRM.js 11.35 Kb
├─ video_player.bundle.UO3KNN5D.js 120.59 Kb
├─ web_form.bundle.PZ4D2XJB.js 1564.12 Kb
├─ print_format_builder.bundle.4NK3JYLN.js 170.41 Kb
├─ build_events.bundle.L2HAVD4K.js 11.62 Kb
└─ kanban_board.bundle.AHRTMM5S.js 27.87 Kb
frappe/dist/css/
├─ desk.bundle.FDCSGWHG.css 549.26 Kb
├─ email.bundle.XXLSLIM6.css 4.02 Kb
├─ login.bundle.ZQ33BOIF.css 27.85 Kb
├─ print.bundle.P45PYX5D.css 196.50 Kb
├─ print_format.bundle.N56JVME7.css 179.01 Kb
├─ report.bundle.OBT4AB64.css 5.36 Kb
├─ web_form.bundle.QMAAIEUZ.css 14.73 Kb
└─ website.bundle.6PHX6AZV.css 424.29 Kb
frappe/dist/css-rtl/
├─ desk.bundle.B2UOILHH.css 549.51 Kb
├─ email.bundle.VSTQ3FOG.css 4.02 Kb
├─ login.bundle.UOU432ZW.css 27.84 Kb
├─ print.bundle.SDJJGZKK.css 196.65 Kb
├─ print_format.bundle.NWMJH2AM.css 179.13 Kb
├─ report.bundle.KUUFQY5Q.css 5.35 Kb
├─ web_form.bundle.CC54N5TN.css 14.72 Kb
└─ website.bundle.KQX67XCU.css 424.44 Kb
DONE Total Build Time: 35.594s
WARN Cannot connect to redis_cache to update assets_json
WARN Cannot connect to redis_cache to update assets_json
WARN Cannot connect to redis_cache to update assets_json
Done in 40.19s.
SUCCESS: Bench frappe-bench initialized
erpnext@vps:~$ Switch directory into the Frappe Bench directory,
cd frappe-benchChange user directory permissions to set execution permission to the home directory,
chmod -R o+rx /home/[frappe-user]Create a New Site,
bench new-site dev1.domainhere.infoIt'll prompt you to set the password for Administrator user, can set strong password
Output:
erpnext@vps:~/frappe-bench$ bench new-site erp.domainhere.info
MySQL root password:
Installing frappe...
Updating DocTypes for frappe : [========================================] 100%
Updating country info : [========================================] 100%
Set Administrator password:
Re-enter Administrator password: Replace dev1.domainhere.info with actual domain name
Install ERPNext and other Apps
Download all the apps using below commands,
Download payments app using below command,
bench get-app paymentsDownload ERPNext app using below command,
bench get-app --branch version-14 erpnextDownload hrms using below command,
bench get-app hrms Install all the apps on our site
bench --site dev1.domainhere.info install-app erpnext
bench --site dev1.domainhere.info install-app hrmsStart the bench using below command,
bench startNote: This instances which are running on develop mode, this will not get started when you restart your server. You will need to run the bench start command every time the server restarts.
In the below steps, we will learn how to deploy the production mode.
Setting ERPNext for Production Usage
Enable Scheduler
bench --site dev1.domainhere.info enable-schedulerOutput:
erpnext@vps:~/frappe-bench$ bench --site erp.domainhere.info enable-scheduler
Enabled for erp.domainhere.info
erpnext@vps:~/frappe-bench$Disable maintenance mode,
bench --site dev1.domainhere.info set-maintenance-mode offSetup production config,
sudo bench setup production dev1.domainhere.infoSetup NGINX to apply the changes,
bench setup nginxInstall supervisor using below command,
sudo apt install supervisorRestart Supervisor and Launch Production Mode,
sudo supervisorctl restart all
sudo bench setup production [frappe-user]If you are prompted to save the new/existing config file, respond with a Y.
When this completes doing the settings, your instance is now on production mode and can be accessed using your IP, without needing to use the port.
This also will mean that your instance will start automatically even in the event you restart the server.
Setup Let’s Encrypt SSL/TLS Certificates with NGINX
Download the Let’s Encrypt Client,
sudo apt-get install certbot python3-certbot-nginxTo obtain SSL certificate need to update all the packages with required versions,
pip install urllib3==1.26.15 requests-toolbelt==0.10.1 Obtain the SSL/TLS Certificate
While installing Erpnext the frappe-bench.conf file already created by system, so need to obtain the SSL/TCL Certificate,
sudo certbot --nginx -d dev1.domainhere.infoOutput:
Congratulations! You have successfully enabled https://dev1.domainhere.info
-------------------------------------------------------------------------------------
IMPORTANT NOTES:
Congratulations! Your certificate and chain have been saved at:
/etc/letsencrypt/live/dev1.domainhere.info/fullchain.pem
Your key file has been saved at:
/etc/letsencrypt/live/dev1.domainhere.info//privkey.pem Navigate Erpnext
Done.
